AVENTOS HK-XS

Virtually tool-free assembly

The assembly of AVENTOS HK-XS components is virtually tool free. Adjust the lift mechanism precisely to the weight and size of the front and AVENTOS HK-XS will open, close and hold with reliable ease. Combine it with CLIP top BLUMOTION hinges and the small stay lift will close softly and effortlessly.

Easy assembly and adjustment

Blum_KLA0503_MO_FOT_FO_BAU_#SALL_#AOF4_#V1

Symmetrical fittings

AVENTOS HK-XS’s lift mechanism, front and cabinet fixing brackets are all symmetrical.

Blum_KLA0505_MO_FOT_FO_BAU_#SALL_#AOF4_#V1

Soft close

Combine AVENTOS HK-XS with CLIP top BLUMOTION hinges for soft and effortless closing.

Blum_KLA0507_MO_FOT_FO_BAU_#SALL_#AOF4_#V1

CLIP mechanism

The tried and tested CLIP mechanism is tool-free, quick and easy.

Blum_KLA0508_MO_FOT_FO_BAU_#SALL_#AOF4_#V1

Infinitely variable power setting

Use a cordless screwdriver to precisely adjust the lift mechanism to the weight of the front. And the front will hold in any position.

Blum_KLA0510_MO_FOT_FO_BAU_#SALL_#AOF4_#V1

3-dimensional adjustment

Easy 3-dimensional adjustment produces perfect gap alignment.

Assembly instructions

AVENTOS HK-XS

PDF | 1 MB | 11-26-2020

AVENTOS HK-XS special applications

PDF | 1 MB | 07-13-2023

AVENTOS HK-XS standard applications

PDF | 797 KB | 07-13-2023

Assembly videos

AVENTOS HK-XS

This video demonstrates the simple assembly of AVENTOS HK-XS, the lift mechanism adjustment and the three-dimensional adjustment options using CLIP top BLUMOTION.

AVENTOS HK-XS adjustment options

The adjustment options for height, side and depth of the front are shown in this sequence.

Assembly devices

Blum offers a wide range of drilling and insertion machines, assembly devices and templates to ensure that the assembly of Blum products is accurate, quick and easy, for optimal performance requires precise assembly.

Go to Assembly Device Selector
