Cabinet Configurator

Total support from planning to manufacturing

Plan entire cabinets in your web browser – free of charge and without any manual updates..

Configure cabinets with Blum fittings in just a few clicks. An integrated collision check allows you to carry out precise and error-free planning. The comprehensive planning results provide optimal process support: during planning, designing, ordering and manufacturing.

Start the Cabinet Configurator

Advantages for cabinet makers with and without CAD software:

The comprehensive software with a straightforward user interface allows the cabinet and fittings to be visualised in 3D
Save frequently used cabinet dimensions as standard values
Changes to the cabinet design can also be made after fittings planning
Use the Product Configurator to easily select pull-out, hinge and lift systems
Export the CAD data in the most common formats to import into your CAD software or use our BXF* file for existing interfaces
Send components lists directly to the web shop or to customer services of selected distributors when you are ready to order
You can use our cutting lists, assembly overview or manufacturing drawings – digitally or you can print them out
Use the BXF* file to send the planning results to MINIPRESS with EASYSTICK
Save and manage your planning data in "My projects/My order lists"

*The BXF file not only contains information about the fitting, but also manufacturing information for wooden parts,
such as cutting dimensions and drilling positions.

BXF is compatible with an increasing number of partner software products and can be easily transferred to drilling and insertion machines with EASYSTICK.

1

5

Customised standard values

Save frequently used cabinet dimensions as standard values. Changes to the cabinet design can also be made after fittings planning.

2

5

Front planning

One-part or two-part fronts of different materials - everything is possible. The Cabinet Configurator will automatically calculate the front weight.

3

5

Internal design

Plan fixed and adjustable shelves, central panels and line drillings quickly and simply with drag & drop in the Cabinet Configurator.

4

5

Fittings selection

Save valuable time for fittings planning by duplicating fittings at the click of a mouse or creating your own custom fittings templates.

5

Planning results

Comprehensive planning results provide optimal process support: from the concept, planning and the quotation right through to design, ordering and manufacturing.

Videos

Plan several central panels

Are you planning furniture with two, three or more central panels? Now you can add as many central panels as required to the cabinet. The number of central panels is unlimited.

SPACE STEP

Make the plinth functional. SPACE STEP not only allows you to use higher cabinets, but also creates extra storage space in the plinth. And now also possible with the Cabinet Configurator.

Flexible front planning

Do you want flexible front planning? Move horizontal and vertical gaps to the front and this will give you maximum flexibility for enhanced customisation. Select a front and change it to an open compartment with just one click.

Divide back

Are you planning an open compartment without a back, e.g. for electronic devices? Select the element that has already been planned in the interior construction and activate the "divide back" function. Then click on the back that is no longer required and activate "no back".

Divide front widths and heights

You can now divide front heights as well as widths with just a few clicks. Do you want to now plan large fronts, fronts in the tier system or with fixed values? All it takes is a few seconds to turn your desire into reality.

Help function

Use the practical Help function in the Cabinet Configurator by clicking with the mouse in a value range. See how this works in the video.

Blum services

Your key to more efficiency: personal services, digital services, logistics services, assembly devices, communication services

HKi planning

With AVENTOS HKi, we have created the first invisible fitting for stay lifts. You can now also plan the integrated stay lift in the Cabinet Configurator with just a few clicks.

Cabinet Configurator - Plan AVENTOS HF top, HS top, HL top and HK top

All AVENTOS lift system types are now available in a compact top version – be it a fold up, swing up and over, lift up or pivot up system. You can now also plan AVENTOS HF top, HS top, HL top and HK top quickly and easily in the Cabinet Configurator.

Sharing projects or transferring them to EASYSTICK

In the Cabinet Configurator, you can conveniently share your projects with others via email or transfer them directly to EASYSTICK via WLAN. Watch the video to find out just how easy this is.

Optimised menu

We've combined Design and Cabinet design in a single menu item, so all the information you enter when designing the cabinet is in one place.

New toolbar

The new toolbar is now visible right on the fitting: the Duplicate, Edit and Delete functions are there right where you need them.

Adjust a fixed shelf or central panel

Fixed shelves and central panels can now be lengthened or shortened in relation to adjacent elements.

Settings

You would like to adjust your Cabinet Configurator to suit your needs? The new dark mode as well as the possibility of displaying the dimensions of the wooden parts/required space for fittings make this possible. Both functions can be activated and deactivated via the settings menu in the upper right corner.
