Cabinet Configurator

Total support from planning to manufacturing

Plan entire cabinets in your web browser – free of charge and without any manual updates..

Configure cabinets with Blum fittings in just a few clicks. An integrated collision check allows you to carry out precise and error-free planning. The comprehensive planning results provide optimal process support: during planning, designing, ordering and manufacturing.

Advantages for cabinet makers with and without CAD software:

  • The comprehensive software with a straightforward user interface allows the cabinet and fittings to be visualised in 3D
  • Save frequently used cabinet dimensions as standard values
  • Changes to the cabinet design can also be made after fittings planning
  • Use the Product Configurator to easily select pull-out, hinge and lift systems
  • Export the CAD data in the most common formats to import into your CAD software or use our BXF* file for existing interfaces
  • Send components lists directly to the web shop or to customer services of selected distributors when you are ready to order
  • You can use our cutting lists, assembly overview or manufacturing drawings – digitally or you can print them out
  • Use the BXF* file to send the planning results to MINIPRESS with EASYSTICK
  • Save and manage your planning data in "My projects/My order lists"

*The BXF file not only contains information about the fitting, but also manufacturing information for wooden parts,
such as cutting dimensions and drilling positions.

BXF is compatible with an increasing number of partner software products and can be easily transferred to drilling and insertion machines with EASYSTICK.

Customised standard values

Save frequently used cabinet dimensions as standard values. Changes to the cabinet design can also be made after fittings planning.

Front planning

One-part or two-part fronts of different materials - everything is possible. The Cabinet Configurator will automatically calculate the front weight.

Internal design

Plan fixed and adjustable shelves, central panels and line drillings quickly and simply with drag & drop in the Cabinet Configurator.

Fittings selection

Save valuable time for fittings planning by duplicating fittings at the click of a mouse or creating your own custom fittings templates.

Planning results

Comprehensive planning results provide optimal process support: from the concept, planning and the quotation right through to design, ordering and manufacturing.

Videos

Cabinet Configurator trailer
Trailer for the Cabinet Configurator with the most important advantages.
SPACE STEP
Make the plinth functional. SPACE STEP not only allows you to use higher cabinets, but also creates extra storage space in the plinth. And now also possible with the Cabinet Configurator.
Plan several central panels
Are you planning furniture with two, three or more central panels? Now you can add as many central panels as required to the cabinet. The number of central panels is unlimited.
Flexible front planning
Do you want flexible front planning? Move horizontal and vertical gaps to the front and this will give you maximum flexibility for enhanced customisation. Select a front and change it to an open compartment with just one click.
Divide back
Are you planning an open compartment without a back, e.g. for electronic devices? Select the element that has already been planned in the interior construction and activate the "divide back" function. Then click on the back that is no longer required and activate "no back".
Divide front widths and heights
You can now divide front heights as well as widths with just a few clicks. Do you want to now plan large fronts, fronts in the tier system or with fixed values? All it takes is a few seconds to turn your desire into reality.
Cabinet Configurator - Total support from planning to manufacturing
Plan entire cabinets with the free Cabinet Configurator from Blum. Configure Blum fittings using the integrated collision check with just a few clicks. Then submit your order directly through the webshops of selected distributors and benefit from extensive planning results.
Help function
Use the practical Help function in the Cabinet Configurator by clicking with the mouse in a value range. See how this works in the video.
Blum services
Your key to more efficiency: personal services, digital services, logistics services, assembly devices, communication services
Adjusting settings for wooden dowels
Watch the video to find out how you can apply a range of settings for wooden dowels in the Cabinet Configurator. The Help function offers practical support with this.
Configuring a baby changing unit in the Cabinet Configurator
Plan and configure your furniture project with ease in the Cabinet Configurator. The baby changing table is extremely practical and at the same time safe and secure thanks to the high side panels.
Planning a base cabinet with LEGRABOX
Configure a base cabinet with the matching Blum fittings with just a few clicks in the Cabinet Configurator. An integrated collision check allows you to carry out precise and error-free planning.
Planning a sink cabinet with MERIVOBOX
Watch the video to find out how to plan a sink pull-out quickly and easily using the Cabinet Configurator.
Planning a kitchen cabinet with oven
Watch the video to discover how to configure a tall cabinet with appliance door and open cabinet back - perfect for ovens and other electrical appliances in the kitchen.
Sharing projects or transferring them to EASYSTICK
In the Cabinet Configurator, you can conveniently share your projects with others via email or transfer them directly to EASYSTICK via WLAN. Watch the video to find out just how easy this is.
Planning a sideboard with MOVENTO
Watch the video to see a practical sideboard application with MOVENTO.
Planning hinges on a line drilling
In this video, we show you how to plan hinges on a line drilling and how you can change their position individually, simply by dragging and dropping them or using the value range.
Planning SPACE TOWER with SERVO-DRIVE
Watch the video to find out how to plan a SPACE TOWER with SERVO-DRIVE using the Cabinet Configurator.
Saving and loading projects
Save and manage your personal configurations under "My projects". You'll find out more about this in the video.
Planning a wardrobe with TANDEM
The video shows a practical wardrobe solution that you can plan quickly and easily in the Cabinet Configurator.
Plan pull-out shelves with lock-open stop
Pull-out shelves are locked in position exactly where they are needed, be it in the kitchen, bathroom, living room or utility room. Watch the video to find out how to plan pull-out shelves with a pull-out shelf lock in the Cabinet Configurator.

If you have any questions, please get in touch with your personal contact at Blum.
