AVENTOS HK top

Integrated features facilitate installation and adjustment

The fixing position of AVENTOS HK top is the same regardless of application and cabinet height. Once the lift mechanism has been precisely adjusted to the weight of the front, the stay lift will open, close and hold with reliable ease.

Two types of assembly

Choose between two types of symmetrical lift mechanisms – and consequently between two types of assembly. Either pre-drill holes into cabinet side and use pre-mounted system screws to fix lift mechanisms, or simply screw on lift mechanisms with integrated positioning system.

Lift mechanism with positioning system

Simply position this type of lift mechanism so it touches the top panel and is flush with the cabinet face, then screw on. No pre-drilling needed.

Assembly with pre-mounted system screws

This type of lift mechanism is fixed to the cabinet side with two system screws and two pegs. Requires four holes in a horizontal line in system 32 .

Easy assembly and adjustment

No protruding parts

Lever arms are closed so there are no protruding parts. This greatly facilitates in-house transportation.

Integrated safety mechanism

The integrated safety mechanism stops the lever arm from opening unintentionally.

CLIP mechanism

The tried and tested CLIP mechanism is tool-free, quick and easy.

Infinitely variable power setting

Lift mechanisms can be set from the front without having to remove cover caps. Consequently, fronts will stay in any position desired.

3-dimensional adjustment

Adjustment is achieved using TORX screws - quick, easy and low in wear.

Integrated opening angle stop

An opening angle stop with infinitely variable setting has been integrated into the fitting.

Installation instructions

Assembly devices

Blum offers a wide range of drilling and insertion machines, assembly devices and templates to ensure that the assembly of Blum products is accurate, quick and easy. Optimal performance requires precise assembly.
