TIP-ON BLUMOTION for TANDEMBOX
Well-thought-out product details
A special TANDEMBOX cabinet profile has been designed to support the mechanical opening support system. Various nominal lengths and weight ranges can be implemented using the different
Cabinet profile
Load bearing capacity
Nominal length
30 kg
65 kg
Unit and latch set
| Nominal length | Weight range | Unit | Colour coding system |
|---|---|---|---|
| 270-300 mm | ≤ 10 kg 10-20 kg |
S0 S1 |
White Light grey |
| 350-650 mm | ≤ 20 kg 15-40 kg 35-65 kg |
L1 L3 L5 |
Light grey Dust grey Black |
Synchronisation
We recommend using the synchronisation feature to enlarge the trigger range and achieve top quality performance. A synchronisation linkage is used to this end.
Trigger range with and without synchronisation feature
Synchronisation linkage with synchronisation adapters for internal cabinet widths of ≥ 287 mm
One-piece synchronisation can be cut to size for internal cabinet widths of 238 – 286 mm
Case studies
Innovative technology
Extensive trigger range
The synchronisation feature enlarges the trigger range so that even wide and high fronts open with ease.
Extra convenience guaranteed
No worries if your hands are full. Thanks to
Excellent corrosion protection properties in high humidity
TIP-ON BLUMOTION in hallways
Even high and wide fronts open at a single touch thanks to the extensive trigger range.
